AIR Washer 10000 CFM

Name: AIR Washer 10000 CFM
Brand: West Air System
Price: 100000.0 INR
Availability: InStock

Price 100000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

AIR Washer 10000 CFM Specification

Indoor Fan Input
Integrated with main motor

Power Supply
Single Phase / Three Phase

Mounting
Floor Mounted

Temperature Control
Thermostatic / Manual

Dimension (L*W*H)
Custom / Standard (Approx. 2.0m x 1.6m x 2.0m)

Place of Origin
India

Outdoor Fan Input
1.5HP / 2.2KW motor

Cooling Capacity
Approximately 28 kW

Air Flow Capacity
10000 CFM

Condition
New

Power Consumption
2.2 kW - 5.0 kW (Depending on fan/motor)

Refrigerant
N/A (Uses water for cooling)

Sensible control
Yes

Filtration Grade
Pre-filter & Cellulose Pad

Running Current
5~12 Amps (approx.)

Power Mode
AC

Type
Evaporative Air Washer

Cooling/Heating
Cooling

Capacity
10000 CFM (Cubic Feet per Minute)

Power Source
Electric

Voltage
230V / 380V

Color
Blue / Grey

Weight (kg)
Approx. 350-400 kg

Working Temperature
5C to 50C

Fan Speed
Single or Double

Noise Level
Low

Energy Efficiency Rating
High

Remote Operated
Yes

Air Discharge
Top / Side / Down as required

Duct Connection
Suitable for ducting applications

Maintenance Access
Front & Side Service Doors

Warranty on Motor/Pump
6 to 12 months from manufacturer

Noise Level at 1m
~68 dB(A)

Installation Service
Available on Request

Pump Type
Submersible Water Pump

Control Panel
Starters & Overload Protection Included

Application
Industrial, Workshops, Warehouses, Commercial Spaces

Pump Power
0.5 HP

Water Consumption
30-50 litres/hour (approx.)

Corrosion Resistance
Yes

Cooling Media
Cellulose Honeycomb Pads

Material of Construction
GI / Mild Steel with Powder Coating

Humidity Control
Yes

Water Tank Capacity
100-250 Litres

Environment Friendly
Yes, no harmful refrigerants

About AIR Washer 10000 CFM

An Air Handling Unit (AHU) is a central component of a heating, ventilation, and air conditioning (HVAC) system used to regulate and circulate air within a building. The AHU conditions air by filtering, heating, cooling, humidifying, or dehumidifying it to maintain indoor air quality and thermal comfort. It typically consists of a blower or fan, air filters, heating and cooling coils, dampers, and control systems housed within a metal enclosure. AHUs distribute conditioned air through ductwork to occupied spaces and return air back to the unit for reconditioning or exhaust.

A short/simple description
A technical specification-style description
A description for drawings or BOQ
A student-friendly explanation

Superior Cooling for Demanding Environments

The AIR Washer 10000 CFM is meticulously engineered for cooling expansive areas such as warehouses, workshops, and industrial plants. Its high-capacity design ensures effective air circulation and optimal temperature management, even in challenging environments. This evaporative air washer efficiently brings down temperatures while maintaining controlled humidity levels, making it perfect for year-round use in commercial and industrial applications.

Rugged Construction with Corrosion Resistance

Built using high-quality galvanized iron or mild steel with advanced powder coating, the AIR Washer resists corrosion and endures heavy usage. The water tank holds between 100-250 litres, and top-tier pre-filter and cellulose pad filtration keep the unit and your air clean. Maintenance is simple and safe through convenient front and side doors, ensuring longevity and reliability in everyday operations.

Environmentally Friendly and Energy Efficient

This air washer operates without harmful refrigerants, using only water for cooling purposes-a green solution for modern facilities. Its energy-efficient motor and design deliver strong air flow at a lower power consumption of 2.2-5.0 kW, with a running current of 5~12 Amps. Expect effective cooling with reduced operational costs and peace of mind knowing that the system supports a more sustainable workplace.

FAQ's of AIR Washer 10000 CFM:

Q: How does the AIR Washer 10000 CFM control temperature and humidity in large spaces?

A: The AIR Washer uses a powerful evaporative cooling process, drawing warm air through cellulose honeycomb pads saturated with water. This method efficiently cools and humidifies air simultaneously, helping maintain a comfortable environment even in vast warehouses or industrial settings.

Q: What maintenance process is required for the AIR Washer?

A: Routine maintenance includes checking and cleaning the cellulose honeycomb pads, examining water tank levels (100-250 litres), and ensuring the pre-filters are free from debris. Front and side service doors provide easy access, allowing for straightforward inspection and minimal downtime during servicing.

Q: When is this air washer most beneficial for use in commercial spaces?

A: This air washer is ideal during periods of high heat or low humidity, but it also maintains effectiveness throughout the year due to its efficient temperature and humidity control. Its robust cooling is particularly valuable in demanding industrial, workshop, and warehouse environments whenever maintaining controlled conditions is critical.

Q: Where can the AIR Washer 10000 CFM be installed?

A: It can be floor-mounted in a variety of settings including industrial plants, commercial spaces, workshops, and warehouses. Its flexible design allows for top, side, or down air discharge and is suitable for direct or ducted installation according to your building's layout.

Q: What are the benefits of the unit's construction and materials?

A: The washer's GI/mild steel body with powder coating ensures superior durability and corrosion resistance. This makes it well-suited for harsh industrial conditions, providing a longer service life and reducing the need for frequent replacements.

Q: How environmentally friendly is the AIR Washer 10000 CFM?

A: It is highly eco-friendly, operating solely on water with no use of harmful refrigerants. Its energy-efficient design reduces power usage while delivering effective cooling, supporting your sustainability goals.

Q: What warranty and support options are available for this product?

A: The unit comes with a manufacturer's warranty of 6 to 12 months for the motor and pump. Installation and service support are available on request, backed by distributor, manufacturer, and service provider networks across India.
